ISR4431-V/K9 Cisco ISR Router Cisco Isr 4431 Uc Bundle PVDM4-64 UC License

Product Categories

SENYDA(HK)Technology Limited

Contact Now

ISR4431-V/K9 Cisco ISR Router Cisco Isr 4431 Uc Bundle PVDM4-64 UC License

Name: ISR4431VK9 Cisco ISR Router Cisco Isr 4431 Uc Bundle PVDM464 UC License
Brand: Cisco
Price: 5180 USD

China ISR4431-V/K9 Cisco ISR Router Cisco Isr 4431 Uc Bundle PVDM4-64 UC License factory

Brand Name : Cisco

Model Number : ISR4431-V/K9

Certification : FCC

Place of Origin : USA

MOQ : 1/unit

Price : $5180/unit

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 20/unit/day

Delivery Time : 3 days

Packaging Details : Original New Cisco Box Packing

Products Status : In Stock

Application : Enterprise

Warranty : 1 year

USB console port -type B mini (up to 115.2 kbps) : 1

External USB 2.0 slots (type A) : 2

Maximum flash memory : 16GB

Contact Now

SR4431-V/K9 Cisco ISR Router Cisco Isr 4431 Uc Bundle PVDM4-64 UC License

Product Information of ISR4431-V/K9

The Cisco 4000 Series ISRs consolidate many must-have IT functions, including network, compute, and storage resources. The high-performance, integrated routers run multiple concurrent IWAN services, including encryption, traffic management, and WAN optimization, without slowing your data throughput. And you can activate new services on demand through a simple licensing change.

Product Code	Cisco ISR4431/K9
Aggregate Throughput	500 Mbps to 1 Gbps
Total onboard WAN or LAN 10/100/1000 ports	4
RJ-45-based ports	4
SFP-based ports	4
Enhanced service-module (SM-X) slot	0
NIM (Network Interface Modules) slots	3
Onboard ISC slot	1
DDRM (data plane)	2 GB (default) / 2 GB (maximum)
DDRM (control/services plane)	4 GB (default) / 16 GB (maximum)
Flash Memory	8 GB (default) / 32 GB (maximum)
Power-supply options	Internal: AC, DC, and PoE
Rack height	1 RU
Dimensions (H x W x D)	43.9 x 438.15 x 507.2 mm
Package Weight	20.88 Kg

More Details of ISR4431-V/K9

Table below shows the LED descriptions

LEDs	Represents	Color	Description
PSU	Power Supply Unit (P0 and P1) Status	Green	PSU is on and is providing power.
		Amber	PSU is on but with errors or in a failure condition.
		Off	Power supply is turned off.
GE POE	Internal PoE Daughter Card Status	Green	PSU is installed and providing power
		Amber	PSU is installed but in a failure condition.
		Off	PSU is off.
FLASH	System Flash Status	Blinking Green	Compact flash/eUSB flash is present and currently being accessed.
TEMP	Temperature Status	Solid green	All temperature sensors in the system are within acceptable range.
		Amber	One or more temperature sensors in the system are outside the acceptable range.
		Off	Temperature is not being monitored.
PWR	System Power	Green	System power is on and functioning correctly.
		Green blinking	System power is in the process of shutting down.
		Amber	System power is up, but low level initialization failed.
		Amber blinking	System power is up, but the system failed to come out of reset.
		Off	System power is off.
POE BOOST	Power Over Ethernet Boost Mode	Green	Two PoE power supplies are installed and operating in boost mode.
POE BOOST	Power Over Ethernet Boost Mode	Off	This can mean one of the following: ·No PoE PSU installed. ·One PoE PSU installed. ·Two PoE PSUs installed and operating in redundant mode.
ISC	ISC Slot Status	Green	PVDM4 is present and enabled.
		Amber	Initialized with error.
		Off	Not present.
FAN	Fan Status	Green	All fans are operating.
		Amber	One fan has stopped working.
		Blinking Amber	Two or more fans have stopped working, or the fan tray has been removed.
		Off	Fans are not being monitored.
STAT	System Status	Solid green	System operating normally.
		Blinking amber	BIOS/Rommon is booting.
		Amber	BIOS/Rommon has completed booting, and system is at Rommon prompt or booting platform software.
		Off	System is not out of reset or BIOS image is not loadable.

Related Products of ISR4431-V/K9

Table below shows Cisco 4000 Series Performance Licenses

Product	Description
ISR4321-AX/K9	Cisco ISR 4321 AX Bundle w/APP, SEC lic
ISR4321-AXV/K9	Cisco ISR 4321 AXV Bundle, w/APP, SEC, UC lic, CUBE-10
ISR4321-SEC/K9	Cisco ISR 4321 Sec bundle w/SEC license
ISR4321-V/K9	Cisco ISR 4321 Bundle, w/UC License, CUBE-10
ISR4321-VSEC/K9	Cisco ISR 4321 Bundle w/UC & SEC License, CUBE-10
ISR4321/K9	Cisco ISR 4321 (2GE,2NIM,4G FLASH,4G DRAM,IPB)
ISR4331-AX/K9	Cisco ISR 4331 AX Bundle w/ APP,SEC lic
ISR4331-AXV/K9	Cisco ISR 4331 AXV Bundle,PVDM4-32 w/APP,SEC,UC lic,CUBE-10
ISR4331-SEC/K9	Cisco ISR 4331 Sec bundle w/SEC license
ISR4331-V/K9	Cisco ISR 4331 UC Bundle, PVDM4-32, UC License, CUBEE10
ISR4331-VSEC/K9	Cisco ISR 4331 Bundle with UC & Sec Lic, PVDM4-32, CUBE-10
ISR4331/K9	Cisco ISR 4331 (3GE,2NIM,1SM,4G FLASH,4G DRAM,IPB)
ISR4351-AX/K9	Cisco ISR 4351 AX Bundle w/ APP,SEC lic
ISR4351-AXV/K9	Cisco ISR 4351 AXV Bundle,PVDM4-64 w/APP,SEC,UC lic,CUBE-25
ISR4351-SEC/K9	Cisco ISR 4351 Sec bundle w/SEC license
ISR4351-V/K9	Cisco ISR 4351 UC Bundle, PVDM4-64, UC License, CUBEE25
ISR4351-VSEC/K9	Cisco ISR 4351 Bundle with UC & Sec Lic, PVDM4-64, CUBE-25
ISR4351/K9	Cisco ISR 4351 (3GE,3NIM,2SM,4G FLASH,4G DRAM,IPB)
ISR4431-AX/K9	Cisco ISR 4431 AX Bundle with APP and SEC license
ISR4431-AXV/K9	Cisco ISR 4431 AXV Bundle,PVDM4-64 w/APP,SEC,UC lic,CUBE-25
ISR4431-SEC/K9	Cisco ISR 4431 Sec bundle w/SEC license
ISR4431-V/K9	Cisco ISR 4431 UC Bundle, PVDM4-64, UC License, CUBE-25
ISR4431-VSEC/K9	Cisco ISR 4431 Bundle with UC & Sec Lic, PVDM4-64, CUBE-25
ISR4431/K9	Cisco ISR 4431 (4GE,3NIM,8G FLASH,4G DRAM,IPB)
ISR4451-UCSE-S/K9	Cisco ISR 4451 CI Bundle w 24 port SM, UCS-E Single Wide SM
ISR4451-X-AX/K9	Cisco ISR 4451 AX Bundle with APP and SEC license
ISR4451-X-AXV/K9	Cisco ISR 4451 AXV Bundle,PVDM4-64 w/APP,SEC,UC lic,CUBE-25
ISR4451-X-SEC/K9	Cisco ISR 4451 Sec Bundle, w/SEC license
ISR4451-X-V/K9	Cisco ISR 4451 UC Bundle, PVDM4-64, UC Lic,CUBE25
ISR4451-X-VSEC/K9	Cisco ISR 4451 VSEC Bundle, PVDM4-64 w/ UC,SEC Lic,CUBE-25
ISR4451-X/K9	Cisco ISR 4451 (4GE,3NIM,2SM,8G FLASH,4G DRAM)
